RACInverter

RAC - Inverter
Model Number
AS-09UW4SVDTD9A
AS-12UR4SVETD12
AS-18UR4SXATD06
AS-22UXW4SBBTD
Type
Heat pump
Heat pump
Heat pump
Heat pump
Cooling Capacity
W
8200
9400
8800(3400-9500)
9100
Heating Capacity
W
8000
9600
8800(3200-9800)
9200
Refrigerant
R410A
R410A
R410A
R410A
Refrigerant Volume
g
610
800
1320
1670
Indoor Unit Noise Level
High(dB(A))
39
39
44
48
Low(dB(A))
30
30
36
40
Outdoor Unit Noise Level
dB(A)
54
53
56
58
Voltage, Frequency, Phase
220-240V, 50Hz, 1P
220-240V, 50Hz, 1P
220-240V, 50Hz, 1P
220-240V, 50Hz, 1P
Net Dimensions WxHxD (mm)
Indoor Unit
780x270x202
850x270x202
960x315x230
1085x315x235
Outdoor Unit
715x482x240
715x482x240
810x585x280
860x650x310
Net Weight (kg)
Indoor Unit
8.5
8.5
12.5
14.5
Outdoor Unit
24
27
39
47
Packing Dimensions WxHxD (mm)
Indoor Unit
830x335x260
900x335x260
1022x380x302
1170x390x315
Outdoor Unit
830x530x315
830x530x315
940x630x385
995x730x445
Gross Weight (kg)
Indoor Unit
10
11
14.5
17
Outdoor Unit
26
29
42
51
Liquid Pipe
1/4
1/4
1/4
3/8
Gas Pipe
3/8
3/8
1/2
5/8
Load Capacity (20'/40'/40'HC) with pipe
145/298/345
140/285/335
86/180/201
63/131/150
Load Capacity (20'/40'/40'HC) without pipe
135/281/330
134/280/320
86/180/201
63/131/150
Model Number
AS-30HR4SBBTE
AS-36HR4SBBTE
AS-30US4DKV
AS-36UW4SDKD
Type
Heat pump
Heat pump
Heat pump
Heat pump
Cooling Capacity
W
8200
9400
8800(3400-9500)
9100
Heating Capacity
W
8000
9600
8800(3200-9800)
9200
Power Input-Cooling
W
2720
3345
2460(700-27000
2835
Power Input-Heating
W
2490
2990
2460(650-2600)
2545
Moisture Removal
L/H.r
2.2
2.6
3
3
Air Circulation
CMH Max
1200
1680
1800
1800
EER for Cooling
W/W
3.1
2.81
3.58
3.21
COP for Heating
W/W
3.21
3.21
3.95
3.61
Energy Consumption
kWh / year
1360
1673
1180
1245
Energy Class
Cooling
A
A
A
A
Energy Class
Heatling
A+
A+
A+
A+
Refrigerant
R410A
R410A
R410A
R410A
Refrigerant volumn
g
1950
2150
2300
2200
Indoor Unit Noise Level
High(dB (A))
45
50
48
49
Low(dB (A))
42
45
39
40
Outdoor Unit Noise Level
dB (A)
58
64
60
59
Power Supply
Voltage, Frequency, Phase
220-240V~,50Hz,1P
220-240V~,50Hz,1P
220-240V~,50Hz,1P
220-240V~,50Hz,1P
Rated Current
Cooling (A)
12.1
14.8
10,9(3,1-11,7)
13.0
Heating (A)
11.2
14.3
11(2,9-11,3)
11.7
LRA
A
65.6
66
-
-
System
Compressor type
Rotary
Rotary
Rotary
Rotary
Evaporator
Copper tube and Aluminum Fin
Copper tube and Aluminum Fin
Copper tube and Aluminum Fin
Copper tube and Aluminum Fin
Condenser
Copper tube and Aluminum Fin
Copper tube and Aluminum Fin
Copper tube and Aluminum Fin
Copper tube and Aluminum Fin
Connecting Pipe Diameter
Liquid Pipe
inch
3/8
3/8
3/8
3/8
Gas Pipe
inch
5/8
5/8
5/8
5/8
Maximum pipe length
m
15
15
15
15
Maximum height difference
m
5
5
5
5
Features
Display on Front Panel
LED
LED
LED
LED
LCD Wireless Remote Controller
Yes
Yes
Yes
Yes
Removable and washable Panel
Yes
Yes
Yes
Yes
Washable PP Filter
Yes
Yes
Yes
Yes
Active Charcoal Filter
Optional
Optional
Optional
Optional
Electrostatic Filter
Optional
Optional
Optional
Optional
LTC Filter
Optional
Optional
Optional
Optional
Catechin filter
Optional
Optional
Optional
Optional
Negative ion filter
Optional
Optional
Optional
Optional
Photic Catalyst filter
Optional
Optional
Optional
Optional
Vitamin-C filter
Optional
Optional
Optional
Optional
Dimmer
Yes
Yes
Yes
Yes
24 Hours Timer
Yes
Yes
Yes
Yes
Timer ON/OFF
Yes
Yes
Yes
Yes
3 Speed and Auto Indoor Fan Control
Yes
Yes
Yes
Yes
Silent Mode
Yes
Yes
Yes
Yes
Horizontal Auto Swing Louver
Yes
Yes
Yes
Yes
Manual Adjustable Vertical Louver
Yes
Yes
Yes
Yes
Auto Horizontal Louver
Yes
Yes
Yes
Yes
Smart sense function
Yes
Yes
Yes
Yes
Super function
Yes
Yes
Yes
Yes
Compressor Indicator
Yes
Yes
Yes
Yes
Auto Restart
Yes
Yes
Yes
Yes
Auto Defrost
Yes
Yes
Yes
Yes
Dehumidification function
Yes
Yes
Yes
Yes
Cold air protection
Yes
Yes
Yes
Yes
Other (VQ panel)
Net Dimensions WxHxD (mm)
Indoor Unit
1131x315x235
1266x346x262
1280x260x360
1290x348x263
Outdoor Unit
860x650x310
885x795x366
885x795x366
884x793x365
Net Weight (Kg)
Indoor Unit
14.5
19.5
18
17
Outdoor Unit
49
60
60
58
Packing Dimensions WxHxD (mm)
Indoor Unit
1220x400x310
1385x435x325
1365x325x435
1385x435x325
Outdoor Unit
995x730x445
1050x890x445
1050x890x500
1050x890x500
Gross Weight (Kg)
Indoor Unit
17
23
22
21
Outdoor Unit
51
66
66
64
Loading Capacity (20'/40'/40'HC ) without pipe
60/128/144
42/88/108
42/88/108
41/87/106
Approvals
CB
CB+EMC
CB
CB
Test Standard
IRAM 62406
EN 14511
    Remarks:
  • The design and specifications are subject to change without prior notice for product improvement.
  • The values given in the table for noise level reflect the levels in an echoic chamber.
